Hermetic Packaging

Topics : comparisons evaluation of wafer level bonding techniques, gas sources, outgassing profiles of different materials used in MEMS, getter solutions. Novel calculation model for vacuum sealed MEMS lifetime prediction, new analytical method based on single die MEMS residual gas analyses (RGA).


Objectifs du cours

Low cost and reliability are the main important factors for the successful commercialization of MEMs devices. It is possible to decrease packaging costs by shifting from ceramic packages to wafer to wafer level packaging. On the other hand, the ability to maintain the suitable environmental conditions either vacuum or inert gas inside the package of electronics devices like is the key for assuring high reliability performances. The pressure requirements of some hermetically packaged devices such as gyroscopes, resonators, IR bolometers, RF devices and optical mirrors are very stringent.

Due to the desorption phenomena of gaseous species from the internal surfaces, the vacuum inside such a electronic devices, after bonding encapsulation, tends to degrade. Post process vacuum quality control and reliability for hermetic bonding is extremely important for overall device reliability and process yield. In this course we analyze the main factors that are critical in the vacuum design of hermetically sealed devices.

Comparisons evaluation of wafer level bonding techniques, gas sources, outgassing profiles of different materials used in MEMS as well as getter solutions are presented and discussed. We introduce a novel calculation model for vacuum sealed device lifetime prediction. New analytical method based on single die residual gas analyses (RGA) is presented.

Public cible

The course is structured to be supportive to packaging engineers, MEMS bonding process engineers and generally to R&D personals that work in electronics devices design activities.

Contenu

• Why hermetic vacuum packaging is required for electronic devices

• Hermetic packaging technologies available in the market (Wafer level, Discrete)

• Wafer level packaging (Pros and cons of direct Si bonding, glass frit bonding, anodic bonding, eutectic bonding, low temperature direct Si bonding)

• Target pressure and MEMS devices

• Gas sources into MEMS devices (leakage, outgassing, absorbed species, reversible/irreversible desorptions)

• Residual gases inside hermetically sealed devices (RGA analysis in electronics devices: the analytical method, measurements procedure and accuracy, examples of RGA of device with internal volume less than 0.1 mm3, reliability of the data)

• Outgassing measurements (materials and process selections suitable for MEMS in vacuum, outgassing tests methods: static and dynamic measurements)

• Example of outgassing studies in MEMS (MEMS gyroscopes, Micro bolometer)

inscription

Ce cours n'est pas agendé en ce moment. Veuillez nous contacter en cas d'intérêt


» Contactez-nous !

Dès 5 personnes interessées, nous vous contacterons pour chercher une date qui vous convient.

informations

Durée

2 days

Coût

Prix early bird : 1'300.00
Prix normal : 1'500.00

Langue du cours

Anglais

Enseignant(s)
teacher 1

Marco Moraja
